Wheel and Tire Sizing Guide for Tesla Vehicles

Have a question about the the wheels and tires either included on your Tesla Model S / Model 3 / Model X, or what will fit? If so, have a look at our handy guide below detailing wheel and tire sizes and compatibilities!

JUMP TO:

MODEL S  |  MODEL 3  |  MODEL X

JUMP TO:

MODEL S   |  MODEL 3   |   MODEL X

MODEL S

 Below is the collection of OEM wheels offered by Tesla.



19" BASE

These are the wheels originally included as standard on all Model S vehicles. They were replaced in early 2016 with the Slipstream wheels (below).

Size + Offset

19x8.0" +40

Bolt Pattern

5x120

Center Bore

64.1mm

Weight (per wheel)

29.5lbs (13.38kg)

Additional Cost Option?

N/A

Included Tire

All Season:
Michelin Primacy MXM4 - 245/45R19 98W (Overall Diameter: 27.7")
All Season:
Goodyear Eagle RS-A2 -245/45R19 98V (Overall Diameter: 27.7")

19" SLIPSTREAM

The "Slipstream" Wheels were introduced in Early-2016 as the standard option for all Model S vehicles. These replaced the original 19" split-spoke wheels (above).

Size + Offset

19x8.0" +40

Bolt Pattern

5x120

Center Bore

64.1mm

Weight (per wheel)

29lbs (13.15kg)

Additional Cost Option?

N/A

Included Tire

All Season:
Michelin Primacy MXM4 - 245/45R19 98W (Overall Diameter: 27.7")
All Season:
Goodyear Eagle RS-A2 -245/45R19 98V (Overall Diameter: 27.7")


19" CYCLONE

The "Cyclone" Wheels were formerly an paid upgrade option available when purchasing a Model S (they were also available in the Tesla online shop). The Cyclone Wheel is now discontinued.

Size + Offset

19x8.0" +40

Bolt Pattern

5x120

Center Bore

64.1mm

Weight (per wheel)

29.8lbs (13.52kg)

Additional Cost Option?

Yes - $2500.00 USD additional when ordering a Model S. Alternatively, could be purchased as a wheel / tire package from Tesla's online store for $4400.00 USD

Included Tire

All Season:
Michelin Primacy MXM4 - 245/45R19 98W (Overall Diameter: 27.7")
All Season:
Goodyear Eagle RS-A2 -245/45R19 98V (Overall Diameter: 27.7")

21" TURBINE

Available as Tesla's suggested upgrade for all "Performance" Model S vehicles in either a Silver or Metallic Grey finish, the 21" Turbine is probably the most well-known wheel option for the Tesla Model S.

Normally offered as a "staggered" configuration, with a wider rear wheel / tire, during 2015, Tesla briefly offered a "square" configuration, with all 4 wheels utilizing the 21x8.5" wheel before returning to the original staggered offering.

Size + Offset

21x8.5" +40 (FRONT + REAR)
21x9.0" +40 (REAR)

Bolt Pattern

5x120

Center Bore

64.1mm

Weight (per wheel)

8.5" Width: 29.8lbs (15.97kg)
9.0" Width: 38lbs (17.25kg)

Additional Cost Option?

Yes - $4500.00 USD additional when ordering a Model S. Alternatively, could be purchased as a wheel / tire package from Tesla's online store for $6000.00 USD

Included Tire

Summer Performance:
Continental
Contisportcontact 5P -
245/35ZR21 96Y XL (FRONT) (Overall Diameter: 27.8")
265/35ZR21 101Y XL (REAR) (Overall Diameter: 28.3")

Summer Performance:
Michelin Pilot Sport PS2 -
245/35ZR21 96Y XL (FRONT) (Overall Diameter: 27.8")
265/35ZR21 101Y XL (REAR) (Overall Diameter: 28.3")

Image Image


21" ARACHNID

Available only as a reward through Tesla's referral program, the Arachnid wheels are produced from forged aluminum for lighter weight, and are available in three colors - silver, gunmetal grey and black.

Size + Offset

21x8.5" +40 (FRONT)
21x9.0" +40 (REAR)

Bolt Pattern

5x120

Center Bore

64.1mm

Weight (per wheel)

8.5" Width: 25.9lbs (11.75kg)
9.0" Width: 26.95lbs (12.22kg)

Additional Cost Option?

N/A

Included Tire

Summer Performance:
Michelin Pilot Super Sport -
245/35ZR21 96Y XL (FRONT) (Overall Diameter: 27.8")
265/35ZR21 101Y XL (REAR) (Overall Diameter: 28.3")

MODEL S

 Below is the collection of OEM wheels offered by Tesla.



19" BASE

These are the wheels originally included as standard on all Model S vehicles. They were replaced in early 2016 with the Slipstream wheels (below).

Size + Offset

19x8.0" +40

Bolt Pattern

5x120

Center Bore

64.1mm

Weight (per wheel)

29.5lbs (13.38kg)

Additional Cost Option?

N/A

Included Tire

All Season:
Michelin Primacy MXM4 - 245/45R19 98W
All Season:
Goodyear Eagle RS-A2 -245/45R19 98V


19" SLIPSTREAM

The "Slipstream" Wheels were introduced in Early-2016 as the standard option for all Model S vehicles. These replaced the original 19" split-spoke wheels (above).

Size + Offset

19x8.0" +40

Bolt Pattern

5x120

Center Bore

64.1mm

Weight (per wheel)

29lbs (13.15kg)

Additional Cost Option?

N/A

Included Tire

All Season:
Michelin Primacy MXM4 - 245/45R19 98W
All Season:
Goodyear Eagle RS-A2 -245/45R19 98V


19" CYCLONE

The "Cyclone" Wheels were formerly an paid upgrade option available when purchasing a Model S (they were also available in the Tesla online shop). The Cyclone Wheel is now discontinued.

Size + Offset

19x8.0" +40

Bolt Pattern

5x120

Center Bore

64.1mm

Weight (per wheel)

29.8lbs (13.52kg)

Additional Cost Option?

Yes - $2500.00 USD additional when ordering a Model S. Alternatively, could be purchased as a wheel / tire package from Tesla's online store for $4400.00 USD

Included Tire

All Season:
Michelin Primacy MXM4 - 245/45R19 98W
All Season:
Goodyear Eagle RS-A2 -245/45R19 98V

Image Image

21" TURBINE

Available as Tesla's suggested upgrade for all "Performance" Model S vehicles in either a Silver or Metallic Grey finish, the 21" Turbine is probably the most well-known wheel option for the Tesla Model S.

Normally offered as a "staggered" configuration, with a wider rear wheel / tire, during 2015, Tesla briefly offered a "square" configuration, with all 4 wheels utilizing the 21x8.5" wheel before returning to the original staggered offering.

Size + Offset

21x8.5" +40 (FRONT + REAR)
21x9.0" +40 (REAR)

Bolt Pattern

5x120

Center Bore

64.1mm

Weight (per wheel)

8.5" Width: 29.8lbs (15.97kg)
9.0" Width: 38lbs (17.25kg)

Additional Cost Option?

Yes - $4500.00 USD additional when ordering a Model S. Alternatively, could be purchased as a wheel / tire package from Tesla's online store for $6000.00 USD

Included Tire

Summer Performance:
Continental
Contisportcontact 5P -
245/35ZR21 96Y XL (FRONT)
265/35ZR21 101Y XL (REAR)

Summer Performance:
Michelin Pilot Sport PS2 -
245/35ZR21 96Y XL (FRONT)
265/35ZR21 101Y XL (REAR)



21" ARACHNID

Available only as a reward through Tesla's referral program, the Arachnid wheels are produced from forged aluminum for lighter weight, and are available in three colors - silver, gunmetal grey and black.

Size + Offset

21x8.5" +40 (FRONT)
21x9.0" +40 (REAR)

Bolt Pattern

5x120

Center Bore

64.1mm

Weight (per wheel)

8.5" Width: 25.9lbs (11.75kg)
9.0" Width: 26.95lbs (12.22kg)

Additional Cost Option?

N/A

Included Tire

Summer Performance:
Michelin Pilot Super Sport -
245/35ZR21 96Y XL (FRONT)
265/35ZR21 101Y XL (REAR)

MODEL 3

 Below is the collection of OEM wheels offered by Tesla.




18" AERO

These are the wheels included as standard on all Model 3 vehicles.

Size + Offset

18x8.5" +40

Bolt Pattern

5x114.3

Center Bore

64.1mm

Weight (per wheel)

With Aero Cover: 23lbs (10.43kg)
Without Aero Cover: 21.6lbs (9.8kg)

Additional Cost Option?

N/A

Included Tire

All Season:
Michelin Primacy MXM4 - 235/45R18 98W XL (Overall Diameter: 26.3" / Revolutions Per Mile: 790)

19" STILETTO

Also known as the "Sport" Wheel, the "Stiletto" is an optional upgrade when ordering a Model 3.

Size + Offset

19x8.5" +40

Bolt Pattern

5x114.3

Center Bore

64.1mm

Weight (per wheel)

25lbs (11.43kg)

Additional Cost Option?

Yes - $1500.00 USD additional when ordering a Model 3. Alternatively, can be purchased as a winter wheel / tire package from Tesla's online store for $3500.00 USD.

Included Tire

All Season:
Continental Procontact RX - 235/40R19 96W XL (Overall Diameter: 26.4" / Revolutions Per Mile: 787)


20" STILETTO

Starting in March 2018, Tesla began offering a 20" version of their "Stiletto" Wheel / Tire package in their online store.

Size + Offset

20x8.5" +40

Bolt Pattern

5x114.3

Center Bore

64.1mm

Weight (per wheel)

Pending

Additional Cost Option?

Yes - $4000.00 USD additional as a wheel / tire package from Tesla's online store.

Included Tire

Summer Performance:
Michelin Pilot Sport 4S -
235/35ZR20 92Y (Overall Diameter: 26.5" / Revolutions Per Mile: 786)

MODEL 3

 Below is the collection of OEM wheels offered by Tesla.




18" AERO

These are the wheels included as standard on all Model 3 vehicles.

Size + Offset

18x8.5" +40

Bolt Pattern

5x114.3

Center Bore

64.1mm

Weight (per wheel)

With Aero Cover: 23lbs (10.43kg)
Without Aero Cover: 21.6lbs (9.8kg)

Additional Cost Option?

N/A

Included Tire

All Season:
Michelin Primacy MXM4 - 235/45R18 98W XL


19" STILETTO

Also known as the "Sport" Wheel, the "Stiletto" is an optional upgrade when ordering a Model 3.

Size + Offset

19x8.5" +40

Bolt Pattern

5x114.3

Center Bore

64.1mm

Weight (per wheel)

25lbs (11.43kg)

Additional Cost Option?

Yes - $1500.00 USD additional when ordering a Model 3. Alternatively, can be purchased as a winter wheel / tire package from Tesla's online store for $3500.00 USD.

Included Tire

All Season:
Continental Procontact RX - 235/40R19 96W XL


20" STILETTO

Starting in March 2018, Tesla began offering a 20" version of their "Stiletto" Wheel / Tire package in their online store.

Size + Offset

20x8.5" +40

Bolt Pattern

5x114.3

Center Bore

64.1mm

Weight (per wheel)

Pending

Additional Cost Option?

Yes - $4000.00 USD additional as a wheel / tire package from Tesla's online store.

Included Tire

Summer Performance:
Michelin Pilot Sport 4S -
235/35ZR20 92Y

MODEL X

 Below is the collection of OEM wheels offered by Tesla.


Image Image

20" SLIPSTREAM

These are the wheels included as standard on all Model X vehicles. The "Sonic Carbon" Grey version is available for an additional $2000.00 USD when ordering a Model X. Either version is also available as a winter wheel / tire package from the Tesla online store for $5000.00 USD.

Size + Offset

20x9.0" +35
20x9.5" +35
20x10.0" +35 (only available briefly)

Bolt Pattern

5x120

Center Bore

64.1mm

Weight (per wheel)

9.0" Width: 32lbs (14.51kg)
9.5" Width: 33.2lbs (15.06kg)

Additional Cost Option?

Yes - "Sonic Carbon" Grey is $2000.00 USD additional when configuring a Model X. Either Silver or Sonic Grey finishes are available from the Tesla online store as an winter wheel / tire package for $5000.00 USD

Included Tire

All Season:
Continental CrossContact LX Sport - 265/45R20 108V XL (FRONT) (Overall Diameter: 29.4")
275/45R20 110V XL (REAR) (Overall Diameter: 29.7")

Summer:
Michelin Latitude Sport 3 -
255/45R20 105Y XL (FRONT) (Overall Diameter: 29.1")
275/45R20 110Y XL (REAR) (Overall Diameter: 29.8")


19" CYCLONE

Tesla offers the Cyclone wheel through their online store included in a winter wheel / tire package.

Size + Offset

19x8.5" +35

Bolt Pattern

5x120

Center Bore

64.1mm

Weight (per wheel)

29lbs (13.15kg)

Additional Cost Option?

Yes - $2800.00 USD additional as a winter wheel / tire package from Tesla's online store.


20" HELIX

The "Helix" Wheels were formerly an paid upgrade option available when purchasing a Model X. They were also previously offered included in a winter wheel / tire package on the Tesla online store. The Helix Wheel is now discontinued.

Size + Offset

20x9.0" +35
20x10.0" +40

Bolt Pattern

5x120

Center Bore

64.1mm

Weight (per wheel)

~34lbs (15.4kg)

Additional Cost Option?

Yes - $2500.00 USD additional when ordering a Model X. Alternatively, could be purchased as a wheel / tire package from Tesla's online store for $5500.00 USD

Included Tire

All Season:
Continental CrossContact LX Sport - 265/45R20 108V XL (FRONT) (Overall Diameter: 29.4")
275/45R20 110V XL (REAR) (Overall Diameter: 29.7")

Summer:
Michelin Latitude Sport 3 -
255/45R20 105Y XL (FRONT) (Overall Diameter: 29.1")
275/45R20 110Y XL (REAR) (Overall Diameter: 29.8")


22" TURBINE

The 22" version of Tesla's Turbine, it is typically found on "Performance" Model X vehicles in either a Silver or Onyx Black [satin] finish.

The 22" Turbine Wheel set is offered as a "staggered" configuration, with a wider rear wheel / tire.

Size + Offset

22x9.0" +35 (FRONT)
22x10.0" +35 (REAR)

Bolt Pattern

5x120

Center Bore

64.1mm

Weight (per wheel)

9.0" Width: 37.6lbs (17.06kg)
10.0" Width: 40.4lbs (18.33kg)

Additional Cost Option?

Yes - $4500.00 USD additional when ordering a Model X. Alternatively, can be purchased as a wheel / tire package from Tesla's online store for $6800.00 USD

Included Tire

All Season:
Pirelli Scorpion Zero -
265/35ZR22 102W XL (FRONT) (Overall Diameter: 29.3")
285/35ZR22 106W XL (REAR) (Overall Diameter: 29.9")

Summer Performance:
Goodyear Eagle F1 Asymmetric 3 -
265/35R22 102W XL (FRONT) (Overall Diameter: 29.3")
285/35R22 106W XL (REAR) (Overall Diameter: 29.9")
Image Image

MODEL X

 Below is the collection of OEM wheels offered by Tesla.


Image Image

20" SLIPSTREAM

These are the wheels included as standard on all Model X vehicles. The "Sonic Carbon" Grey version is available for an additional $2000.00 USD when ordering a Model X. Either version is also available as a winter wheel / tire package from the Tesla online store for $5000.00 USD.

Size + Offset

20x9.0" +35
20x9.5" +35
20x10.0" +35 (only available briefly)

Bolt Pattern

5x120

Center Bore

64.1mm

Weight (per wheel)

9.0" Width: 32lbs (14.51kg)
9.5" Width: 33.2lbs (15.06kg)

Additional Cost Option?

Yes - "Sonic Carbon" Grey is $2000.00 USD additional when configuring a Model X. Either Silver or Sonic Grey finishes are available from the Tesla online store as an winter wheel / tire package for $5000.00 USD

Included Tire

All Season:
Continental CrossContact LX Sport - 265/45R20 108V XL (FRONT)
275/45R20 110V XL (REAR)

Summer:
Michelin Latitude Sport 3 -
255/45R20 105Y XL (FRONT)
275/45R20 110Y XL (REAR)



19" CYCLONE

Tesla offers the Cyclone wheel through their online store included in a winter wheel / tire package.

Size + Offset

19x8.5" +35

Bolt Pattern

5x120

Center Bore

64.1mm

Weight (per wheel)

29lbs (13.15kg)

Additional Cost Option?

Yes - $2800.00 USD additional as a winter wheel / tire package from Tesla's online store.


20" HELIX

The "Helix" Wheels were formerly an paid upgrade option available when purchasing a Model X. They were also previously offered included in a winter wheel / tire package on the Tesla online store. The Helix Wheel is now discontinued.

Size + Offset

20x9.0" +35
20x10.0" +40

Bolt Pattern

5x120

Center Bore

64.1mm

Weight (per wheel)

~34lbs (15.4kg)

Additional Cost Option?

Yes - $2500.00 USD additional when ordering a Model X. Alternatively, could be purchased as a wheel / tire package from Tesla's online store for $5500.00 USD

Included Tire

All Season:
Continental CrossContact LX Sport - 265/45R20 108V XL (FRONT)
275/45R20 110V XL (REAR)

Summer:
Michelin Latitude Sport 3 -
255/45R20 105Y XL (FRONT)
275/45R20 110Y XL (REAR)


Image Image

22" TURBINE

The 22" version of Tesla's Turbine, it is typically found on "Performance" Model X vehicles in either a Silver or Onyx Black [satin] finish.

The 22" Turbine Wheel set is offered as a "staggered" configuration, with a wider rear wheel / tire.

Size + Offset

22x9.0" +35 (FRONT)
22x10.0" +35 (REAR)

Bolt Pattern

5x120

Center Bore

64.1mm

Weight (per wheel)

9.0" Width: 37.6lbs (17.06kg)
10.0" Width: 40.4lbs (18.33kg)

Additional Cost Option?

Yes - $4500.00 USD additional when ordering a Model X. Alternatively, can be purchased as a wheel / tire package from Tesla's online store for $6800.00 USD

Included Tire

All Season:
Pirelli Scorpion Zero -
265/35ZR22 102W XL (FRONT)
285/35ZR22 106W XL (REAR)

Summer Performance:
Goodyear Eagle F1 Asymmetric 3 -
265/35R22 102W XL (FRONT)
285/35R22 106W XL (REAR)
